CMX 5-Zone Mixer Amplifier – 240W RMS | USB/SD/FM/Bluetooth | Brand New

The CMX 5-Zone Mixer Amplifier (EA-240Z) is a professional 240W RMS public address (PA) amplifier designed for multi-zone paging and background music systems. Featuring 5 independent speaker zones, Bluetooth, USB, SD card, and FM radio playback, plus 7 audio inputs, this amplifier is ideal for schools, offices, shopping centres, warehouses, hotels, restaurants, places of worship, and commercial installations. It supports 100V, 70V, and low-impedance (4–16Ω) speaker systems, providing maximum installation flexibility.

⚙️ Specifications

Brand: CMX
Model: EA-240Z
Type: 5-Zone Mixer Amplifier / PA Amplifier
Rated Power Output: 240W RMS

🎵 Audio Sources

• Bluetooth Audio Streaming
• USB Media Playback
• SD Card Playback
• FM Radio Tuner

🎙 Inputs

• 5 × Balanced XLR Microphone Inputs
• 2 × Auxiliary Inputs (RCA & 6.35mm)
• Total 7 Audio Inputs

🔊 Speaker Outputs

• 5 Independent 100V Speaker Zones
• 100V Output
• 70V Output
• 4Ω, 8Ω & 16Ω Low-Impedance Outputs

🎚 Audio Controls

• Independent Zone Selection
• Mic 1 Priority with Adjustable Mute
• Low, Mid & High Equalizer Controls
• Master Volume Control
• +48V Phantom Power for Mic 1 & Mic 2
• 4-Tone Chime & Siren Trigger Input

🛡 Protection

• Short Circuit Protection
• Overload Protection
• Clip Protection
• High Temperature Protection

⭐ Key Features

• Powerful 240W RMS commercial amplifier
• 5 independent speaker zones
• Bluetooth, USB, SD card and FM playback
• 7 audio inputs for microphones and music sources
• Mic priority for paging and announcements
• Built-in EQ with bass, mid and treble adjustment
• Compatible with 100V, 70V, and 4–16Ω speaker systems
• Designed for reliable 24/7 commercial operation

📦 Package Includes

• Brand New CMX EA-240Z 5-Zone Mixer Amplifier
• Original Retail Box
• Power Cable
• Remote Control
• User Manual
• Original Accessories

📦 Condition

• Brand New
• Original Factory Packaging
• Includes original cables and accessories
• Ready for immediate installation

🎯 Ideal For

• Schools and universities
• Office buildings
• Retail stores
• Hotels and hospitality
• Restaurants and cafés
• Warehouses and factories
• Churches and places of worship
• Public address and background music systems
